Heavy-Duty Lawn Mower with Side Discharge | XH-1023A

High-Efficiency Side Discharge System: Optimized primarily as a professional lawn mower with side discharge system, featuring a rugged discharge chute guard to process heavy clippings across vast acreages quickly.
Heavy-Duty 26HP V-Twin Powertrain: Driven by an 803CC Loncin V-twin 4-stroke OHV engine delivering 19kW @ 3600rpm of continuous, heavy-duty torque for thick, overgrown grass management.
Dual Hydrostatic Drive Transmission: Delivers seamless, clutch-free speed control up to 8.2 km/h forward and 3.7 km/h in reverse, ensuring maximum agility over uneven landscapes.
12-Position Precision Cutting Deck: Features a 42-inch dual-blade steel cutting deck with a 12-gear mechanical lift adjustment ranging from 2.5cm to 10cm.

Product Detail

Product Overview

XH-1023A Commercial Riding Lawn Tractor is a high-capacity engineering solution designed for expansive green spaces, municipal grounds, and professional landscaping fleets. Specifically engineered as a high-performance lawn mower with side discharge, this machine is optimized to process substantial volumes of organic matter efficiently.

At its mechanical core is a premium 26HP (19kW) Loncin V-twin engine coupled with a dual hydrostatic drive system. This configuration allows commercial procurement managers to deploy this commercial lawn mower across diverse and challenging terrains, ranging from manicured institutional turf to rough, overgrown municipal perimeters.

Commercial Selling Points

As illustrated in the technical documentation, the XH-1023A integrates industrial-grade components designed to maximize job site uptime:

01 High-Strength Metal Hood: Built with a durable metal engine cover that optimizes thermal heat dissipation, protects internal components, and contributes to lower operational fuel consumption.
02 12-Position Adjustable Cutting Height: Features a robust mechanical lever providing 12 absolute height settings ( $2.5\text{–}10\text{ cm}$ ) to adapt to variable landscape cultivation requirements.
03 High-Velocity Side Discharge: Configured standard as a heavy-duty lawn mower with side discharge featuring a flexible rubber discharge chute guard, while supporting rear-discharge modifications to satisfy regional commercial preferences.
04 User-Friendly Control Console: Features an ergonomic control panel incorporating an electronic PTO clutch engagement toggle, key ignition switch, and clearly labeled operational functions for intuitive workflow control.

Technical Specifications

Engineering Parameter	Technical Detail / Specification
Product Name	42-inch 26 HP Ride-On Lawn Mower
Model Code / Item No.	XH-1023A / BTW-1023A
Primary Classification	Riding Lawn Mower
HS Code	843319000
Engine Brand & Model	Loncin Engine
Engine Type	V-Twin Cylinder, Air-Cooled, 4-Stroke, OHV
Gross Rated Power	26 HP (19 kW) @ 3600 rpm
Engine Displacement	803 CC
Drive Type	Dual Hydro Static Drive
Transmission Media	Industrial Belt Drive
Cutting Deck Width	42 Inches / High-Vacuum Twin Blade
Cutting Height Range	2.5 cm – 10.0 cm
Deck Lift Mechanism	12-Position Mechanical Manual Lever
PTO Clutch Assembly	Heavy-Duty Electronic Clutch
Grass Discharge Configurations	Lawn Mower with Side Discharge (Supports Rear Conversion)
Ground Speed (Forward / Reverse)	8.2 km/h / 3.7 km/h
Wheel Configuration (Front / Rear)	15" $\times$ 6" / 18" $\times$ 8.5" Heavy-Turf Pneumatic
Starting System	12V Electric Start
Fuel Tank / Engine Oil Capacity	11.36 Liters / 1.9 Liters
Net Weight / Gross Weight	251 kg / 258 kg
Export Case Dimensions	198 $\times$ 130 $\times$ 115 cm (1 Unit / Wooden Crate)
Material Composition	Structural Iron + Die-Cast Aluminum + Reinforced ABS

Commercial Application Scenarios

The high-torque performance profile of the XH-1023A ensures excellent versatility across broad scale operations:

Commercial Turf & Parks: Maximizes hourly cutting coverage on athletic sports fields, municipal parks, golf courses, and estate lawns.
Agricultural & Sloped Topography: Well-suited for orchard mowing, vineyard alley maintenance, and sloped lawns where dual hydrostatic traction control is necessary.
Challenging Ground Clearance: High-ply pneumatic tires allow smooth operations across rough terrain, handling dense, overgrown structural grass without grounding out the deck.

Premium Practical Details

To satisfy the rigorous demands of commercial landscape management and agricultural operations, the XH-1023A is engineered with several premium hardware details that ensure long-term operational reliability:

High-Vacuum Dual Blade System: Equipped with a synchronized twin-blade cutting configuration within the 42-inch deck. The dual-blade layout generates maximum aerodynamic airflow, forcing grass blades upright before cutting to guarantee clean, highly uniform turf truncation.
Heavy-Duty Electronic PTO Clutch: Features a premium electromagnetic PTO (Power Take-Off) clutch system. This eliminates traditional mechanical linkage wear, providing smooth, instantaneous blade engagement and guaranteeing stable, vibration-free running under heavy structural loads.
Engine Thermal Optimization: The high-strength structural metal engine hood is strategically vented to maximize cold air intake and optimize internal heat dissipation. This superior thermal management protects critical V-twin engine seals and extends the operational lifecycle during continuous, long-hour shifts.
All-Terrain Heavy-Turf Pneumatic Tires: Fitted with rugged 15" $\times$ 6" front and 18" $\times$ 8.5" rear pneumatic turf tires. The engineered tread pattern delivers exceptional traction and stability across uneven ground, sloped landscapes, and mud, while minimizing compaction on manicured lawns.
Extended-Range 11.36L Fuel Capacity: Built with a large-capacity 11.36-liter fuel tank. This commercial-grade fuel reservoir drastically reduces frequent refueling intervals on massive commercial jobsites, maximizing daily field efficiency and operator productivity.

About Xinghu Power: Your Strategic Manufacturing Partner

Founded in 1995, Yongkang Xinghu Power Machinery Co., Ltd. (XINGHU) is an elite Chinese manufacturer specializing in high-performance garden machinery, power tools, and industrial fans. As a national standard-setting industrial entity, we operate a fully integrated production supply chain including an in-house Diemaking Shop for precision mold tolerances, a professional Testing Laboratory, and dedicated Commissioning Workshops verifying 100% pre-delivery compliance.

B2B Supply Chain Capabilities:

Certified Global Compliance: Our manufacturing processes hold strict international certifications, including ISO, EPA, CE, Euro V (EURO5), and GSG, ensuring seamless customs clearance across global ports.
Secure Logistics Packaging: To eliminate transit deformation, each unit is secured inside an export-standard wooden box (198 x 130 x 115 cm) engineered for heavy ocean freight handling.
Flexible OEM/ODM Solutions: We support wholesale customization options for corporate accounts, including tailored chassis color schemes (standard red/orange or bespoke brand matches) and private-label logo integration.
